While the Epic EVO sees a seemingly modest 20-millimeter increase in suspension travel up front over its Epic stablemate and just 10-millimeters out back, we’ve worked overtime to make sure it’s been implemented in a way that’ll have you saying ‘Whoa!’ as soon as you hit your first stretch of singletrack.

Meticulously engineered to retain as much of the Epic’s standard-setting efficiency as possible, the EVO’s new suspension kinematics work in concert with Rx XC Tune customized suspension front and rear to ensure you're able to make the absolute most out of every inch of travel on tap, while still offering increased anti-squat characteristics for improved pedaling efficiency.

With plenty of practice at staying ahead of the curve, the Epic EVO now lays claim to the most capable iteration of our Progressive XC Geometry ever to grace an Epic. It’s also more versatile than ever thanks to a new flip chip-equipped rear end that allows riders to adjust headtube angle and bottom bracket height to easily customize Epic EVO’s handling characteristics.

Dressed to impress, the Epic EVO Pro LTD sports top-shelf RockShox suspension front and rear to keep things poised when the going gets rough, while the silky shifts and rock-solid performance of SRAM's 12-speed X0 Eagle AXS group will never go out of style.

Flip It To Rip It: Tune the ride of the Epic EVO’s FACT 11m carbon frame to match your preferred handling characteristics with flip-chip simplicity that allows riders to reduce the EVO’s headtube angle by half a degree while lowering bottom bracket height by 10 millimeters.

Pairing the stiff yet lightweight SID Ultimate chassis with RockShox's lightest-ever Charger Race Day damper makes for quite the package, impressively cutting weight while still managing to pack in truly impressive levels of performance, precsion, and control.

The X0 Eagle AXS groupset utilizes the proven backbone of SRAM 1x, 520-percent gear range, a more secure and longer-wearing X-Sync 2 chainring, and the resilience of an aluminum cage paired with the connected components of Eagle AXS.

Descending from a long World Cup lineage, hand-built Roval Control Carbon wheels feature a modern 29-millimeter internal-width hookless rim and straight-pull DT Swiss 350 hubs to maximize strength, ride quality, and durability while keeping weight to a minimum.

Occasionally, without notice, manufacturers change product design and/or specifications.

Frame	FACT 11m Full Carbon, Progressive XC Geometry, Rider-First Engineeredâ„¢, threaded BB, 12x148mm UDH compatible rear spacing, internal cable routing, 110mm of travel
Fork	Rockshox SID ULTIMATE, Charger Race Day Damper, Debon Air, 15x110mm, 44mm offset, 120mm Travel
Rear Shock	RockShox SID LUXE ULTIMATE, Rx XC Tune, Two Position, Rebound Adjust, 190x40mm
Stem	TruVativ Descendant 35, 35mm clamp, 60mm
Bars	Roval Control Rise Carbon Handlebar, 760mm wide, 20mm rise, 35mm
Front Brake	SRAM Level Silver Stealth, 4-piston caliper, hydraulic disc, stealth, 180mm rotor
Rear Brake	SRAM Level Silver Stealth, 4-piston caliper, hydraulic disc, stealth, 180mm rotor
Brake Lever	SRAM Level
Rear Mech	SRAM X0 Eagle AXS
Shifters	SRAM AXS POD Controller
Speed	12
Rims	Roval Control, Carbon offset design, 29mm internal width, 4mm hook width, Tubeless ready, 28h
Front Hub	DT Swiss 350, 6-bolt, 15mm Thru-axle, 110mm spacing, 28h straight -pull
Rear Hub	DT Swiss 350 straight-pull, 6-bolt, DT Swiss Ratchet EXP, 12x148mm thru axle, Microspline freehub body, 28h straight-pull
Spokes	DT Swiss Comp Race
Front Tyre	Specialized Ground Control, GRID Casing, T7 Compound, 29x2.35
Rear Tyre	Specialized Ground Control, GRID Casing, T7 Compound, 29x2.35
Seat Post	Bike Yoke Revive, 30.9mm, SM: 125, MD: 160mm, L/XL: 185mm,
Saddle	Body Geometry Power Expert
Chainset	SRAM X0 Eagle Crankset, 170mm/175mm. 32T
Bottom Bracket	SRAM DUB Threaded Wide
Chain	SRAM X0 Eagle Flat Top
Cassette	SRAM X0 Eagle 10-52t
Pedals	Resin Platform

Height	Bike Size	Mountain Bike Size
4’8” – 5’1” 143 – 155 cm	XXS	13” (33 cm)
5’1” – 5’4” 155 – 163 cm	XS	15” (38 cm)
5’4” – 5’7” 163 – 170 cm	S	16” (41 cm)
5’7” – 5’10” 170 – 178 cm	M	18” (46cm)
5’10” – 6’0” 178 – 183 cm	L	19” (48cm)
6’0” – 6’3” 183 – 191 cm	XL	20” (51 cm)
6’3” – 6’5” 191 – 196 cm	XXL	21” (53 cm)
6’5” – 6’9” 196 – 205 cm	XXXL	22” (56 cm)
