Cube Reaction Hybrid Pro 800 FE Trapeze 2026 - Electric Mountain Bike
The Cube Reaction Hybrid Pro 800 FE Trapeze is a versatile e-bike built for mixed riding, the Reaction Hybrid Pro FE Trapeze combines mountain bike capability with practical accessories and powerful Bosch assistance.
Key Features:
- Aluminium Superlite Trapeze frame with Agile Ride Geometry
- SR Suntour X1-32 Air fork, 120mm travel (100mm small sizes)
- No rear suspension, efficient hardtail design
- Shimano XT 12-speed drivetrain
- Shimano MT420 hydraulic disc brakes, 4-piston
- 29"/27.5" wheels with Schwalbe Smart Sam 2.6" tyres
- Fully equipped with lights, rack, mudguards & kickstand
- Available with 0% APR finance
Drive Information:
- Bosch Performance Line CX motor, up to 100Nm torque
- Bosch PowerTube 800Wh battery
- Bosch Smart System display with handlebar remote
The Cube Reaction Hybrid Pro 800 FE Trapeze is designed to cover a wide range of riding, from weekday commuting to weekend exploring. The Trapeze frame offers easier access while maintaining the strength and stability needed for longer rides and carrying luggage.
Bosch’s Performance Line CX motor delivers strong, consistent support, helping you maintain momentum on climbs and longer routes. Paired with an 800Wh battery, it offers the range to go further with confidence, and it’s also PowerMore-ready for an additional range extender if needed.
Up front, the SR Suntour air fork smooths out rough roads and trails, with up to 120mm of travel providing added comfort and control. Wide Schwalbe Smart Sam tyres offer dependable grip across mixed terrain, making it just as comfortable on gravel paths as it is on tarmac.
Shimano’s XT 12-speed drivetrain gives you a wide gear range for tackling varied gradients, while 4-piston Shimano hydraulic disc brakes provide consistent stopping power, especially useful when riding with added weight from luggage.
What sets this model apart is its full equipment package. Mudguards, integrated lighting, a sturdy rear carrier and a kickstand come fitted as standard, making it ready for daily use straight out of the box. Combined with internal cable routing and a clean frame design, it’s a practical and capable e-bike for riders who want one bike to do it all.
Occasionally, without notice, manufacturers change product design and/or specifications.
| Frame | Aluminium Superlite, Gravity Casting Technology, Agile Ride Geometry, Boost148, Fully Integrated Battery, Advanced Internal Cable Routing, 1.5 Headtube, Kickstand/Fender/Carrier Mounting Points |
| Fork | SR Suntour X1-32 LO-R Air, Tapered, 15x110mm, 120mm (27.5: 100mm) |
| Headset | ACROS AZF-1034, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), X-Connect Interface |
| Stem | CUBE Performance Stem E-MTB 35, FPI-Link |
| Bars | CUBE Rise Trail Bar 35 |
| Front Brake | Shimano BR-MT420, Hydr. Disc Brake (203) |
| Rear Brake | Shimano BR-MT420, Hydr. Disc Brake (203) |
| Rear Mech | Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed |
| Shifters | Shimano Deore SL-M6100-IR, Direct Attach |
| Speed | 12 |
| Rims | ACID SLX 30, 32/32 Spokes, 15x110mm/12x148mm, Tubeless Ready |
| Front Hub | ACID SLX 30, 32/32 Spokes, 15x110mm/12x148mm, Tubeless Ready |
| Rear Hub | ACID SLX 30, 32/32 Spokes, 15x110mm/12x148mm, Tubeless Ready |
| Front Tyre | Schwalbe Smart Sam, Active, 2.6 |
| Rear Tyre | Schwalbe Smart Sam, Active, 2.6 |
| Seat Post | CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm |
| Saddle | ACID Sequence 160 |
| Chainset | ACID MTB Hybrid Pro, 38T |
| Chain | KMC e12 |
| Cassette | Shimano Deore CS-M6100, 10-51T |
| Battery Size (WH) | Bosch PowerTube 800 |
| Motor | Bosch Drive Unit Performance Line CX max. 100Nm (BDU38) |
Cube Reaction Hybrid Size Chart
|
Size |
Height (cm) |
Height (in) |
|
S - 15" |
160 - 170 |
5'5" - 5'7" |
|
M - 17" |
168 - 175 |
5'6" - 5'9" |
|
L - 19" |
175 - 185 |
5'9" - 6'1" |
|
XL - 21" |
185 - 190 |
6'1" - 6'3" |
|
XXL - 23" |
190 - 196 |
6'3" - 6'5' |
What size frame do I need if I am between sizes? - read here
