(1)Product ID: 273087
Giant Defy Advanced E+ Elite AR 2025 - Electric Road Bike
This model comes with 700x35c SCHWALBE G-ONE ALLROUND Perf tyres for added versatility on rough roads and gravel. The new SyncDrive Move Plus motor, which delivers up to 30Nm of support (equivalent to 75Nm with a mid-drive motor) in a lightweight, quiet system, is cleanly integrated into the rear hub and features five support levels and Smart Assist technology to determine optimal pedalling support for a smooth, natural riding experience. The system is powered by the EnergyPak 400 battery, which provides powerful support in an integrated, lightweight package.
With its smooth-riding composite frame, lightweight battery, new SyncDrive Move Plus integrated rear hub motor and all-road ready 38mm tyres, the Defy Advanced E+ AR is the ideal choice for performance-minded road riders who want to tackle steep hills, maintain higher speeds, and experience road riding with no limitations.
Key Performance Factors
With its smooth-riding composite frame, lightweight battery, new SyncDrive Move Plus integrated rear hub motor and all-road ready 38mm tyres, the Defy Advanced E+ AR is the ideal choice for performance-minded road riders who want to tackle steep hills, maintain higher speeds, and experience road riding with no limitations.
Key Performance Factors
SEAMLESS POWER
The SyncDrive Move Plus motor is integrated into the rear hub and delivers 30Nm of power (equivalent to 75Nm with a mid-drive motor) directly to the rear wheel. Weighing just 1.7kg, it’s specially tuned for the pedaling pattern of performance road riding, with minimal energy loss and more torque at higher speeds. The result is a natural feel when accelerating or maintaining steady power at speed, and no motor drag while freewheeling or coasting.
SYSTEM INTEGRATION
The down tube integrated EnergyPak 400 battery system weighs just 2.3kg and is purpose-built for the specific needs of E-bikes. A top tube mounted RideControl Go button makes it quick and easy to turn the E-bike on or off and change power modes. Smart Assist technology uses three sensors to precisely measure the power being applied to the pedals and produce just the right amount of support for a smooth, natural ride experience. All models feature SRAM wireless electronic shifters and an integrated taillight.
PURE ROAD PERFORMANCE
A lightweight composite frameset and high-performance components including a D-Fuse seatpost and handlebars for compliance, integrated WheelSystems with all-road ready 35mm tubeless tires, and a wireless electronic drivetrain all add up to a smooth, efficient ride quality that mirrors the award-winning performance of the Defy endurance road bike range.
Occasionally, without notice, manufacturers change product design and/or specifications.
| Frame | Advanced-grade composite,12x145 thru-axle |
| Fork | Advanced SL-Grade Composite, Full-Composite OverDrive Aero Steerer, 12x100mm thru-axle, Disc |
| Stem | Contact SL Aerolight 31.8 alloy |
| Bars | Giant Contact SL D-Fuse 31.8 alloy |
| Front Brake | Sram Rival eTap HRD, Paceline 160mm center-lock [F] 160mm 6-bols [R] |
| Rear Brake | Sram Rival eTap HRD, Paceline 160mm center-lock [F] 160mm 6-bols [R] |
| Brake Lever | SRAM Rival eTap AXS HRD |
| Rear Mech | SRAM Rival XPLR eTap AXS |
| Shifters | Sram Rival eTap AXS 1x12 |
| Speed | 12 |
| Rims | Giant P-X2 Alloy Disc Wheel System, Tubeless Ready, 19mm inner width, 12mm thru-axle, w/ Sapim spoke E-Light [R] Race [F], e-bike optimised |
| Spokes | Sapim spoke E-Light [R] Race [F], e-bike optimised |
| Front Tyre | SCHWALBE G-ONE ALLROUND Perf, RaceGuard, Brown side-wall 700x35C 67EPI Tubeless |
| Rear Tyre | SCHWALBE G-ONE ALLROUND Perf, RaceGuard, Brown side-wall 700x35C 67EPI Tubeless |
| Seat Post | Giant D-Fuse, composite, 14mm offset |
| Saddle | Giant Approach |
| Chainset | Sram X-SYNC 46T BCD107 chain ring Praxis E Crank Carbon ISIS |
| Bottom Bracket | Giant E+ System BBSS |
| Chain | SRAM Rival 12-speed |
| Cassette | Sram Apex XPLR XG-1251, 10x44T, 12-speed |
| Battery Size (WH) | EnergyPak Smart 400Wh by Panasonic, Aluminium casing with highest safety standard (UL2271, EN50604), CO2 Neutral production, 2300 charging cycles. EnergyPak Plus 200 range extender compatible |
| Motor | SyncDriveMove Plus Hub drive 75Nm max |
| User Interface | Giant RideControl GO, frame-integrated LED console Optional wireless ANT+ display |
Giant Road E Sizing & Geometry
|
Inside Leg (Inches) Vs Rider Height (Feet & Inches) |
27” |
28” |
29” |
30” |
31” |
32” |
33” |
34” |
35” |
36” |
37” |
|
5’ 5” |
|
S |
S |
S |
|
|
|
|
|
|
|
|
5’ 6” |
S |
S |
S |
S |
S |
|
|
|
|
|
|
|
5’ 7” |
|
S |
S |
S |
S |
S |
|
|
|
|
|
|
5’ 8” |
|
S |
S |
M |
M |
M |
|
|
|
|
|
|
5’ 9” |
|
|
M |
M |
M |
M |
M |
|
|
|
|
|
5’ 10” |
|
|
M |
M |
M |
M |
M |
|
|
|
|
|
5’ 11” |
|
|
|
M |
M |
M/L |
M/L |
M/L |
|
|
|
|
6’ 0” |
|
|
|
M/L |
M/L |
M/L |
M/L |
M/L |
|
|
|
|
6’ 1” |
|
|
|
|
M/L |
M/L |
M/L |
L |
L |
|
|
|
6’ 2” |
|
|
|
|
L |
L |
L |
L |
L |
|
|
|
6’ 3” |
|
|
|
|
L |
L |
L |
L |
L |
L |
|
|
6’ 4” |
|
|
|
|
|
|
L |
L |
XL |
XL |
XL |
|
6’ 5” |
|
|
|
|
|
|
XL |
XL |
XL |
XL |
XL |
Giant Road E Geometry
| S | M | ML | L | XL | |
|---|---|---|---|---|---|
| SEAT TUBE LENGTH (mm) | 450 | 475 | 500 | 525 | 550 |
| SEAT TUBE ANGLE | 74.0° | 73.5° | 73.0° | 73.0° | 72.5° |
| TOP TUBE LENGTH (mm) | 545 | 550 | 560 | 575 | 595 |
| HEAD TUBE LENGTH (mm) | 110 | 130 | 150 | 170 | 190 |
| HEAD TUBE ANGLE | 72.0° | 72.0° | 72.0° | 72.0° | 72.0° |
| FORK RAKE (mm) | 50 | 50 | 50 | 50 | 50 |
| TRAIL (mm) | 62.9 | 62.9 | 62.9 | 62.9 | 62.9 |
| WHEELBASE (mm) | 1045 | 1046 | 1051 | 1066 | 1080 |
| CHAIN STAY LENGTH (mm) | 455 | 455 | 455 | 455 | 455 |
| BOTTOM BRACKET DROP (mm) | 70 | 70 | 70 | 70 | 70 |
| STACK (mm) | 549 | 568 | 587 | 606 | 625 |
| REACH (mm) | 387 | 381 | 380 | 389 | 398 |
| HANDLEBAR WIDTH (mm) | 400 | 420 | 420 | 420 | 440 |
| STEM LENGTH (mm) | 90 | 100 | 100 | 110 | 110 |
| CRANK LENGTH (mm) | 170 | 170 | 170 | 170 | 170 |
| WHEEL SIZE | 700c | 700c | 700c | 700c | 700c |
