Giant TCR Advanced Pro Disc 1 Di2 2024 - Road Bike
The Giant TCR Advanced Pro Disc 1 Di2 is designed with an advanced-grade composite frame and full-composite OverDrive 2 steerer fork, it seamlessly combines stiffness-to-weight ratio with strategically shaped aero tubes, ensuring faster climbs and explosive accelerations. The Shimano 105 Di2 hydraulic drivetrain delivers smooth, reliable shifting, while the integrated disc brakes provide powerful stopping power for total control in various conditions.
Key Features:
- Frame: Advanced-grade composite, disc
- Fork: Advanced-grade composite, full-composite OverDrive 2 steerer, disc
- Brakes: Shimano 105 Di2 hydraulic, Giant MPH rotors (160mm front, 140mm rear)
- Drivetrain: Shimano 105 Di2 24-speed
- Wheels: Giant SLR 1 36 Carbon Disc Wheelsystem (36mm front, 36mm rear)
- Tyres: Giant Gavia Course 1, Tubeless, 700x25c (28mm)
- Available with 0% APR Finance
The Shimano 105 Di2 hydraulic drivetrain takes shifting to a new level, providing smooth, precise gear changes with the touch of a button. Integrated disc brakes, featuring flat mounts and thru-axles, offer unparalleled stopping power and control, especially in variable weather conditions.
The Giant SLR 1 36 Carbon Disc Wheelsystem, equipped with Giant Gavia Course 1 tubeless tyres, complements the bike's performance, providing a perfect balance of speed, grip, and reliability. The Giant Variant composite seat post and Fleet SL saddle enhance rider comfort, making this bike a joy to ride over extended distances.
Occasionally, without notice, manufacturers change product design and/or specifications.
| Frame | Advanced-Grade Composite, disc |
| Fork | Advanced-Grade Composite, full-composite OverDrive 2 steerer, disc |
| Stem | Giant Contact SL XS:80mm, S:90mm, M:100mm, M/L:110mm, L:110mm, XL:120mm |
| Bars | Giant Contact SL XS:40cm, S:40cm, M:42cm, M/L:42cm, L:44cm, XL:44cm |
| Front Brake | Shimano 105 Di2 hydraulic, Giant MPH rotors [F]160mm, [R]140mm |
| Rear Brake | Shimano 105 Di2 hydraulic, Giant MPH rotors [F]160mm, [R]140mm |
| Brake Lever | Shimano 105 DI2 |
| Front Mech | Shimano 105 Di2 |
| Rear Mech | Shimano 105 Di2 |
| Shifters | Shimano 105 Di2 |
| Speed | 24 |
| Rims | Giant SLR 1 36 Carbon Disc WheelSystem, [F] 36mm, [R] 36mm |
| Front Hub | Giant Low Friction Hub, CenterLock, 12mm thru-axle [R |
| Rear Hub | Giant Low Friction Hub, 30t ratchet driver, CenterLock, 12mm thru-axle |
| Spokes | SAPIM CX-Ray |
| Front Tyre | Giant Gavia Course 1, tubeless, 700x25c (28mm), folding |
| Rear Tyre | Giant Gavia Course 1, tubeless, 700x25c (28mm), folding |
| Seat Post | Giant Variant, composite, -5/+15mm offset |
| Saddle | Giant Fleet SL |
| Chainset | Shimano 105, 36/52 with Giant Pro Power Meter. XS:170mm, S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm |
| Bottom Bracket | Shimano, press fit |
| Chain | KMC X12 |
| Cassette | Shimano 105, 12-speed, 11x34 |
| Pedals | Resin Platform |
Giant TCR Advanced 2024 Size Chart
|
Size |
Height (cm) |
Height (feet) |
|
XS |
157 - 169 |
5’2” - 5’7” |
|
S |
165 - 175 |
5’5” - 5’9” |
|
M |
171 - 181 |
5’7” - 5’11” |
|
M/L |
177 - 187 |
5’10” - 6’2” |
|
L |
183 - 193 |
6’0” - 6’4” |
|
XL |
189 - 199 |
6’2” - 6’6” |
What size frame do I need if I am between sizes? - read here
Giant TCR Advanced 2024 Geometry
| XS | S | M | M/L | L | XL | |
|---|---|---|---|---|---|---|
| SEAT TUBE LENGTH (mm) | 425 | 445 | 470 | 500 | 530 | 560 |
| SEAT TUBE ANGLE | 74.5° | 74.0° | 73.5° | 73.0° | 73.0° | 72.5° |
| TOP TUBE LENGTH (mm) | 520 | 535 | 550 | 565 | 580 | 600 |
| HEAD TUBE LENGTH (mm) | 120 | 130 | 145 | 165 | 185 | 200 |
| HEAD TUBE ANGLE | 71.0° | 72.3° | 73.0° | 73.0° | 73.0° | 73.0° |
| FORK RAKE (mm) | 45 | 45 | 45 | 45 | 45 | 45 |
| TRAIL (mm) | 72.1 | 64 | 59.2 | 59.2 | 59.2 | 59.2 |
| WHEELBASE (mm) | 976 | 977 | 980 | 991 | 1006 | 1020 |
| CHAIN STAY LENGTH (mm) | 405 | 405 | 405 | 405 | 405 | 405 |
| BOTTOM BRACKET DROP (mm) | 72 | 70 | 70 | 67 | 67 | 67 |
| STACK (mm) | 517 | 528 | 545 | 562 | 581 | 596 |
| REACH (mm) | 376 | 383 | 388 | 393 | 402 | 412 |
| STAND OVER HEIGHT (mm) | 706 | 725 | 747 | 773 | 800 | 816 |
| HANDLEBAR WIDTH (mm) | 400 | 400 | 420 | 420 | 440 | 440 |
| STEM LENGTH (mm) | 80 | 90 | 100 | 110 | 110 | 120 |
| CRANK LENGTH (mm) | 170 | 170 | 172.5 | 172.5 | 175 | 175 |
| WHEEL SIZE | 700C | 700C | 700C | 700C | 700C | 700C |
