Giant Trance X E+ 1 Pro 29er 2021 - Electric Mountain Bike
Faster up the climbs, longer loops, more singletrack fun on any given day with the Giant Trance X E+ 1 Pro 29. Give yourself the freedom to extend your trail-riding adventures with this powerful, smooth-riding 29er.
Key Features:
- ALUXX SL-grade Aluminium frame with fully integrated battery and carbon rocker
- Fox Float DPX2 Performance Shock Controls the 140mm of rear-wheel travel
- Fox 36 Float Performance Elite Fork gives 150mm of plush suspension travel
- Shimano XT/XTR 12-speed drivetrain for slick shifting
- Sizes: S, M, L, XL
- Colours: Polish Silver
- The Giant Trance X E+ 1 Pro 29" 2021 is available with 0% APR finance
Drive Information:
- Motor: Giant SyncDrive Pro 80Nm
- Battery: Giant EnergyPak Smart 625Wh
- Interface: Giant RideControl Ergo
- Connectivity: Bluetooth & ANT+, Smartphone App
The SyncDrive Pro motor gives the new Trance X E+ Pro 29 a massive 80Nm of torque and 360 per cent tunable support, all controlled by the new Giant E-bike App. This gives you the freedom to ride trails the way you want to. You can choose full power to ease your pedalling effort or tune it less aggressively to get more of a workout. Featuring 140mm of smooth Maestro suspension travel in the rear, 150mm upfront, and progressive frame geometry that’s designed for 29-inch wheels, this is a whole new way to tackle technical singletrack trails. The EnergyPak 625Wh battery is cleanly integrated into the downtube of the lightweight ALUXX SL frame.
KEY PERFORMANCE FACTORS
Smooth, powerful support
SyncDrive Pro motor delivers 80Nm of torque and tunable support ratios up to 360 per cent. Smart Assist technology creates smooth pedal assistance that engages instantly when human power is applied, giving you reliable performance on steep climbs and at low speeds.
29er confidence and control
Optimised Maestro suspension for 29-inch wheels with 140mm rear/ 150mm front travel to roll over rough terrain with balance and stability, giving you more momentum for technical climbs and the confidence to fly on fast, rugged singletrack descents.
Adjustable Frame Geometry
Flip-chip lets you change the headtube and seat tube angles, along with the bottom bracket height, to fine-tune the handling. You can choose the low position (65.8/76.0 head/seat tube angle and 30mm BB drop) for faster, open terrain or high (66.5/76.7 head/seat tube angle and 20mm drop) for slower, tighter singletrack.
How far can I expect to ride on a single battery charge?
The range for a single battery charge can vary greatly depending on conditions such as the combined weight of the rider and cargo; wind resistance; tyre pressure and tread profile; terrain and elevation changes; road or trail surface; outdoor temperature; maintenance of the E-Bike; and the condition of the battery.
Conditions are categorized as extreme, good and ideal. Extreme conditions typically occur when riding with a heavy load, strong headwinds or excessive climbs.
ENERGYPAK 625 / SYNCDRIVE PRO Range
- Extreme: 32 miles
- Good: 65 miles
- Ideal: 111 miles
All Tredz bikes are:
- Fully built & ready to ride
- Fully checked & tested by Cytech qualified mechanics
- Available with 0% APR finance on any basket over £99
- UK price match guarantee
- 365 day no hassle returns
- Free delivery in the UK Mainland on a date that suits you
In the box with every Tredz bike is:
- Free Tredz 9 key trail tool
- Free Tredz pedal spanner
- Free basic pedals
- Tredz drawstring kit bag
- 16 point quality control check sheet
- Basic bike setup instructions
- Free Cycle Plan insurance voucher
Occasionally, without notice, manufacturers change product design and/or specifications.
Frame | ALUXX SL-grade Aluminium, Advanced Forged Composite Upper Rocker, 140mm Maestro Suspension System, 'Boost' 148x12QR, ISS, Giant EnergyPak Plus Range Extender Compatible |
Fork | Fox 36 Float Performance Elite, 150mm travel, 44mm offset, FIT4, 3Pos-Adj. Damper, Boost 110x15QR, e-optimized |
Rear Shock | Fox Float DPX2 Performance, EVOL Large Volume sleeve, 3-Pos Lever, 185x52.5mm Trunnion mount |
Stem | Giant Contact SL 35 |
Bars | Giant Contact 35 Trail, 35x780mm |
Front Brake | Shimano Deore XT, BR-M8120, 4-piston, hydraulic disc, 203mm |
Rear Brake | Shimano Deore XT, BR-M8120, 4-piston, hydraulic disc, 203mm |
Front Mech | MRP 1X custom "V3" co-moulded TR chain guide |
Rear Mech | Shimano Deore XTR, 12-Speed, Shadow+ |
Shifters | Shimano Deore XT, 12-speed I-spec EV |
Speed | 12 |
Rims | Giant e-TR1 29, Tubeless ready, 30mm inner width |
Front Hub | Giant e-TR1 110x15 Thru-axle |
Rear Hub | Giant e-TR1 148x12mm Thru-axle |
Spokes | Giant e-TR1 |
Front Tyre | Maxxis Assegai 29x2.6" foldable, Tubeless, EXO, 3c MaxxTerra |
Rear Tyre | Maxxis Dissector 29x2.6" Foldable, Tubeless, EXO+, 120tpi 3C Compound |
Seat Post | Giant Contact Switch, dropper, 30,9mm (S:125, M: 150, L/XL:170) |
Saddle | Giant Romero Trail |
Chainset | Praxis WaveTM 36T Cold Forged 4130 premium steel Praxis e-Cadet+ custom forged crankarm set (Q-factor=168, S:160, M/L:165, XL:170) |
Chain | KMC e.12 Turbo, EcoProteq, e-bike optimised |
Cassette | Shimano CS-M7100-12, 10-51T, 12-speed |
Pedals | Resin Platform |
Battery Size (WH) | Giant EnergyPak Smart 625, 36V Integrated Lithium-Ion |
Motor | Giant SyncDrive Pro |
User Interface | Giant RideControl Ergo |
Giant Trance E Sizing & Geometry
Inside Leg (Inches) Vs Rider Height (Feet & Inches) |
26” |
27” |
28” |
29” |
30” |
31” |
32” |
33” |
34” |
35” |
36” |
37” |
5’ 3” |
|
|
S |
S |
S |
|
|
|
|
|
|
|
5’ 4” |
S |
S |
S |
S |
S |
|
|
|
|
|
|
|
5’ 5” |
S |
S |
S |
S |
S |
|
|
|
|
|
|
|
5’ 6” |
|
S |
S |
S |
S |
S |
|
|
|
|
|
|
5’ 7” |
|
|
S |
S |
S |
M |
M |
|
|
|
|
|
5’ 8” |
|
|
|
M |
M |
M |
M |
M |
|
|
|
|
5’ 9” |
|
|
|
M |
M |
M |
M |
M |
|
|
|
|
5’ 10” |
|
|
|
|
M |
M |
M |
M |
M |
|
|
|
5’ 11” |
|
|
|
|
M |
M |
M |
M |
M |
|
|
|
6’ 0” |
|
|
|
|
|
M |
M |
L |
L |
L |
|
|
6’ 1” |
|
|
|
|
|
L |
L |
L |
L |
L |
|
|
6’ 2” |
|
|
|
|
|
|
L |
L |
L |
L |
L |
|
6’ 3” |
|
|
|
|
|
|
L |
L |
L |
L |
L |
|
6’ 4” |
|
|
|
|
|
|
|
L |
L |
XL |
XL |
XL |
Giant Trance E Geometry
S | M | L | XL | |
---|---|---|---|---|
SEAT TUBE LENGTH (mm) | 406 | 445 | 482 | 507 |
SEAT TUBE ANGLE | 74.0° | 74.0° | 74.0° | 74.0° |
TOP TUBE LENGTH (mm) | 585 | 610 | 630 | 655 |
HEAD TUBE LENGTH (mm) | 95 | 100 | 110 | 130 |
HEAD TUBE ANGLE | 66.5° | 66.5° | 66.5° | 66.5° |
FORK RAKE (mm) | 46 | 46 | 46 | 46 |
TRAIL (mm) | 109 | 109 | 109 | 109 |
WHEELBASE (mm) | 1184 | 1210 | 1231 | 1259 |
CHAIN STAY LENGTH (mm) | 470 | 470 | 470 | 470 |
BOTTOM BRACKET DROP (mm) | 15 | 15 | 15 | 15 |
STACK (mm) | 579 | 584 | 593 | 611 |
REACH (mm) | 418 | 442 | 460 | 479 |
STAND OVER HEIGHT (mm) | 739 | 740 | 772 | 792 |
HANDLEBAR WIDTH (mm) | 780 | 780 | 780 | 780 |
STEM LENGTH (mm) | 40 | 50 | 50 | 60 |
CRANK LENGTH (mm) | 165 | 170 | 170 | 170 |
WHEEL SIZE | 27.5+ | 27.5+ | 27.5+ | 27.5+ |
