Designed for the open road and beyond, the Merida Silex 7000 is a highly capable gravel bike that balances stability and agility with its carbon frame and modern geometry. Equipped with a Shimano GRX drivetrain and powerful hydraulic disc brakes, this bike is ready for any adventure, from smooth roads to rugged trails.
Key Features:
- Frame: CF2 carbon, gravel geometry; max tyre clearance 700x45c
- Fork: Full carbon with tapered steerer for precise handling
- Drivetrain: Shimano GRX820 12-speed for smooth, reliable shifting
- Brakes: Shimano GRX820 hydraulic disc brakes with 180mm rotors
- Wheels: Easton EA70 AX, lightweight and durable
- Tyres: Maxxis Rambler 700x45c; versatile tread with puncture protection
- Standout Feature: Five bottle mounts for custom luggage configurations
- Finance Option: Available with 0% APR finance
The Merida Silex 7000, now in its second generation, brings refined off-road capability with a 1.5-degree slacker head angle and larger-volume tyres, ensuring confidence on rough terrain. Built around a CF2 carbon frame with inboard disc mounts and Disc Cooler technology, the Silex 7000 keeps its braking performance efficient even on extended descents. Its progressive gravel geometry, long top tube and head tube, short stem, mirrors mountain bike handling, making it stable and responsive on diverse surfaces.
The Shimano GRX820 12-speed drivetrain delivers precise and quiet shifting, while the Shimano hydraulic disc brakes ensure reliable stopping power with the 180mm rotors. Equipped with Easton EA70 AX wheels and Maxxis Rambler tyres, the Silex 7000 handles a range of surfaces with excellent grip and durability.
The Silex is designed for versatile adventures, featuring multiple mounting points for bottles, racks, and bags, as well as the option to add mudguards for wetter conditions. With a focus on comfort, control, and load-carrying capacity, the Merida Silex 7000 is built to go the distance, from daily commutes to weekend exploration.
Occasionally, without notice, manufacturers change product design and/or specifications.
| Frame | CF2 carbon II, gravel geometry for stable but nimble handling. Tapered head tube Inboard disc mounts. Threaded BB, 142 x12mm axle standard, disc cooler technology, Max tyre size 700 x 45c (42c with mudguards) |
| Fork | Silex CF2 II; Full carbon; tapered steerer, 100 x12mm axle standard; Max tyre size: 700 x 45c (42c with mudguards) |
| Headset | 320.52.631 |
| Stem | Merida Team CC III; aluminium; 31.8mm diameter; -6 degree rise - Length - 80mm (all sizes) |
| Bars | Merida Expert GRII; aluminium; 400mm (XS-S) , 420mm (M) , 440mm (L/XL) |
| Front Brake | Shimano GRX820; Hydraulic disc brake caliper with Shimano RT64; 180mm rotor |
| Rear Brake | Shimano GRX820; Hydraulic disc brake caliper with Shimano RT64; 180mm rotor |
| Brake Lever | Shimano GRX820 |
| Rear Mech | Shimano GRX822 |
| Shifters | Shimano GRX820 |
| Speed | 12 |
| Rims | Part of wheelset - Easton EA70 AX; 24mm inner rim width; 20mm rim depth; aluminium |
| Front Hub | Part of wheelset - Easton EA70 AX; 100 x 12mm; Centerlock |
| Rear Hub | Part of wheelset - Easton EA70 AX; 142 x 12mm; Centerlock |
| Spokes | part of wheelset |
| Front Tyre | Maxxis Rambler; 700 x 45C; Kevlar bead; TR; EXO |
| Rear Tyre | Maxxis Rambler; 700 x 45C; Kevlar bead; TR; EXO |
| Seat Post | Merida Expert CC; 27.2mm diameter; 15mm layback; Carbon |
| Saddle | Merida Expert SL; V-mount; including Merida minitool |
| Chainset | Shimano GRX820; 42 tooth chainset; Crank length - 170mm (XS/S), 172.5mm (M), 175mm (L/XL) |
| Bottom Bracket | Shimano SM-BBR60 |
| Chain | Shimano M7100 |
| Cassette | Shimano CS-M7100; 10-51 teeth; 12 speed |
| Pedals | Resin Platform |
Merida Silex 2025 Size Chart
| Size | Rider Height (Inch) | Rider Height (cm) |
|---|---|---|
| XS | 5'3" – 5'5" | 162 – 167 |
| S | 5'4" – 5'9" | 165 – 177 |
| M | 5'7" – 5'11" | 173 – 185 |
| L | 5'10" – 6'2" | 181 – 192 |
| XL | 6'1" – 6'5" | 188 – 200 |
What size frame do I need if I am between sizes? - read here
Merida Silex 2025 Geometry Chart
| Size | XS | S | M | L | XL |
|---|---|---|---|---|---|
| Tyre Size | 28" | 28" | 28" | 28" | 28" |
| Seat Tube Length (alloy frame) | 440 | 470 | 500 | 530 | 560 |
| Top Tube Length (horizontal) | 550 | 565 | 580 | 600 | 620 |
| Chainstay Length | 430 | 430 | 430 | 430 | 430 |
| Head Tube Angle | 69.5° | 69.5° | 69.5° | 69.5° | 69.5° |
| Seat Tube Angle | 74.5° | 74.5° | 74.5° | 74.5° | 74.5° |
| Bottom Bracket Drop | 75 | 75 | 75 | 75 | 75 |
| Head Tube Length | 130 | 150 | 170 | 190 | 210 |
| Fork Length | 415 | 415 | 415 | 415 | 415 |
| Reach | 392 | 402 | 412 | 426 | 441 |
| Stack | 570 | 588 | 607 | 626 | 645 |
| Wheelbase | 1048 | 1065 | 1082 | 1104 | 1126 |
| Standover Height | 744 | 771 | 798 | 825 | 852 |
| Seat Tube Length (carbon frame) | 460 | 490 | 520 | 550 | 580 |
All measurements are in mm unless otherwise stated.
The above table shows the standard geometry for the bicycle as shipped, other geometry configurations may be available with certain bikes. Please contact us via Live Chat to find out more.
