Scott Axis eRIDE Evo 2020 - Electric Mountain Bike
One bike to look after everything! Able to bring you comfort on the oldest cobbled streets fun on gravel roads and with a rack, lights and fenders convenient for day to day life. The Scott Axis eRIDE Evo is more than just an electric bike.
Key Features:
- Aluminium alloy frame with integrated battery pack
- Suntour XCR34 fork offers 130mm of plush suspension travel
- X-Fusion NUDE shock controls the 130mm of rear wheel travel
- Shimano XT 1x12 speed drivetrain for a very wide gear range
- Shimano hydraulic disc brakes for all-weather stopping power
- Rack, mudguards and lights ready fitted
- Sizes: Small, Medium, Large, X Large
- Colours: Green
- The Scott Axis ERIDE Evo is available with 0% APR finance
Drive information:
- Motor: Bosch Performance Line CX, 75Nm
- Battery: Bosch 625Wh downtube integrated battery pack
- User Interface / Display: Bosch Purion
Highlights:
- Axis eRIDE EVO Alloy Frame
- SR Suntour XCR34 Air 130mm Fork
- X-Fusion Nude, TwinLoc
- Shimano XT/SLX 12 Speed
- Bosch Perf CX, 625Wh Power Tube
- Shimano BR-MT520 Disc Brakes
- Racktime carrier 15KG
- Schwalbe G-One Allround Perf. Tires
- Kickstand, Syncros Parts
- Supernova M99 mini, rear Tail Light
Occasionally, without notice, manufacturers change product design and/or specifications.
| Frame | Alloy | Virtual 4 link kinematic VLK - 29" | Boost 148x12mm - 130mm travel | Bosch 600W integr. DT Battery - Tapered Headtube |
| Fork | SR Suntour XCR34 Air | Tapered | S-XL 29"/ 130mm Travel | 15x110 bolt Axle | Remote Lock Out |
| Rear Shock | X-Fusion NUDE Trunnion - SCOTT custom w. travel | geo adj. - 3 modes: Lockout-Traction Control -Descend - Reb. Adj. - Travel 130-85-Lockout | 185X50mm |
| Headset | Syncros FL2.0 Press Fit E2 | Tapered 1.5"-1 1/8" - OD 50/62mm | ID 44/56mm |
| Stem | Syncros FL3.0 with front Light mount and Kiox mount |
| Bars | Syncros 3.0 720mm | 31.8mm | 8° | 20mm rise - Syncros Lock On Grip |
| Front Brake | Shimano BR-MT520 4 Piston - 203mm SM-RT64 CL Rotor |
| Rear Brake | Shimano BR-MT520 4 Piston - 203mm RT-EM600 CL Rotor |
| Front Mech | SCOTT Chainguide |
| Rear Mech | Shimano XT | 12 Speed |
| Shifters | Shimano SLX Trigger |
| Speed | 12 |
| Rims | Syncros MAXX Disc | 32H - Tubeless ready |
| Front Hub | Formula CL 811 | 15x110mm |
| Rear Hub | Shimano FH-M7110-B | Boost 12x148mm |
| Spokes | Sapim double butted |
| Front Tyre | Schwalbe G-One Allround Performance - 29x2.25" |
| Rear Tyre | Schwalbe G-One Allround Performance - 29x2.25" |
| Seat Post | Syncros FL3.0 | 31.6mm |
| Saddle | Syncros M3.0 |
| Chainset | FSA CK-745 IS GEN4 MTB 170MM | 38T FSA Mega Tooth Boost Spider |
| Chain | Shimano CN-M7100 MTB 12S |
| Cassette | Shimano CS-M7100-12 10-51T 12S |
| Pedals | VP VPE-506 |
| Battery Size (WH) | 625wh |
| Motor | Bosch Gen4 Performance CX |
| User Interface | Kiox Display |
Electric Bike Bike Size Chart
|
Height |
e Bike Size |
e Road Bike Size |
e Mountain Bike Size* |
|
4’8” – 5’1” 143 – 155 cm |
XXS |
44 cm |
13” (33 cm) |
|
5’1” – 5’4” 155 – 163 cm |
XS |
48 cm |
15” (38 cm) |
|
5’4” – 5’7” 163 – 170 cm |
S |
51 cm |
16” (41 cm) |
|
5’7” – 5’10” 170 – 178 cm |
M |
54 cm |
18” (46cm) |
|
5’10” – 6’0” 178 – 183 cm |
L |
56 cm |
19” (48cm) |
|
6’0” – 6’3” 183 – 191 cm |
XL |
58 cm |
20” (51 cm) |
|
6’3” – 6’5” 191 – 196 cm |
XXL |
60 cm |
21” (53 cm) |
|
6’5” – 6’9” 196 – 205 cm |
XXXL |
62 cm |
22” (56 cm) |
* Mountain bikes are sized differently to road bikes. Typically, they are sized in inches as the first MTBs were produced in the USA. European brands like Lapierre and Haibike like to use centimeters for all their bikes. The measurements of their mountain bikes doesn’t match their road bikes but is like a simple conversion from the inches measurement. This is why we have included cm measurements in brackets for the e mountain bike column.
See our bike size guide for more on bike sizing
