Scott Spark RC Team Issue AXS 29" Mountain Bike 2022 - Trail Full Suspension MTB
Occasionally, without notice, manufacturers change product design and/or specifications.
| Frame | Spark RC Carbon HMF#Integrated Suspension Technology#Flex Pivot / Adjustable head angle#Syncros Cable Integration System#BB92 / UDH Interface / 12x148mm with 55mm Chainline |
| Fork | RockShox SID Select RL3 Air#Custom Charger 3-Mode Damper#15x110mm Maxle Stealth / 44mm offset / Tapered steerer#Lockout / Reb. Adj. / 120mm travel |
| Rear Shock | RockShox NUDE 5 RL3 Trunnion#SCOTT custom w. travel / geo adj.#3 modes: Lockout-Traction Control-Descend#Debon Air / Reb. Adj./ Travel 120-80-Lockout / T165X45mm |
| Headset | Syncros - Acros Angle adjust & Cable Routing HS System#+-0.6° head angle adjustment#ZS56/28.6 – ZS56/40 MTB |
| Stem | Syncros XC 1.5#Syncros Cable Integration System#-12° rise / 7050 Alloy / 31.8mm / 1 1/8" |
| Bars | Syncros Fraser 1.5 XC Alloy 7075 D.B.#Flat Bar / 8° / 740mm#Syncros Pro lock-on grips |
| Front Brake | Shimano XT M8100 Disc, Shimano SM-RT76 / 6 Bolt / 180/F and 160/R |
| Rear Brake | Shimano XT M8100 Disc, Shimano SM-RT76 / 6 Bolt / 180/F and 160/R |
| Rear Mech | SRAM GX Eagle AXS / 12 Speed#Wireless Electronic Shift System |
| Shifters | SRAM GX Eagle AXS Rocker Controller |
| Speed | 12 |
| Rims | Syncros Silverton 2.0-30 6 Bolt#F: 15x110mm, R: 12x148mm#30mm Tubeless ready rim / 28H / XD Driver#Syncros Axle w/Removable Lever#with 6mm Allen, T30 and T25 Tools |
| Front Tyre | Maxxis Rekon Race / 29x2.4" / 120TPI Foldable Bead#Tubeless Ready / EXO |
| Rear Tyre | Maxxis Rekon Race / 29x2.4" / 120TPI Foldable Bead#Tubeless Ready / EXO |
| Seat Post | Syncros Duncan 1.5 / 10mm offset#31.6x400mm |
| Saddle | Syncros Belcarra Regular 1.5#Titanium rails |
| Chainset | SRAM GX Eagle DUB#55mm CL / 32T |
| Bottom Bracket | SRAM DUB PF 92 MTB Wide / shell 41x92mm |
| Chain | SRAM CN GX Eagle |
| Cassette | SRAM XG1275 / 10-52 T |
| Pedals | Resin Platform |
Mountain Bike Size Chart
|
Height
|
Bike Size
|
Mountain Bike Size
|
|
4’8” – 5’1”
143 – 155 cm
|
XXS
|
13” (33 cm)
|
|
5’1” – 5’4”
155 – 163 cm
|
XS
|
15” (38 cm)
|
|
5’4” – 5’7”
163 – 170 cm
|
S
|
16” (41 cm)
|
|
5’7” – 5’10”
170 – 178 cm
|
M
|
18” (46cm)
|
|
5’10” – 6’0”
178 – 183 cm
|
L
|
19” (48cm)
|
|
6’0” – 6’3”
183 – 191 cm
|
XL
|
20” (51 cm)
|
|
6’3” – 6’5”
191 – 196 cm
|
XXL
|
21” (53 cm)
|
|
6’5” – 6’9”
196 – 205 cm
|
XXXL
|
22” (56 cm)
|
* Mountain bikes are sized differently to road bikes. Typically, they are sized in inches as the first MTBs were produced in the USA. European brands like Lapierre and Haibike like to use centimetres for all their bikes. The measurements of their mountain bikes doesn’t match their road bikes but are like a simple conversion from the inches measurement. This is why we have included cm measurements in brackets for the Mountain bike column.
Read our bike size guide for more information on sizing.
