Specialized Turbo Levo SL Comp Alloy 2025 - Electric Mountain Bike
Built around an M5 alloy frame with FOX suspension and SRAM drivetrain, the Turbo Levo SL Comp Alloy provides a reliable, comfortable ride. Designed for trail riders, it blends lightweight performance with easy-to-control power on climbs and descents alike.
Key Features:
- M5 alloy frame, 150mm travel, adjustable head angle and BB height
- FOX FLOAT 36 Rhythm fork, GRIP damper, 140-150mm travel
- FOX FLOAT Performance rear shock, GENIE technology, 150mm travel
- SRAM GX Eagle 12-speed drivetrain for smooth, efficient shifting
- SRAM Maven Bronze brakes with 200mm Centerline rotors
- 29” alloy wheels with Butcher and Eliminator tyres, 2.3” width
- X-Fusion Manic dropper post with infinite adjustability
- Available with 0% APR finance options
Drive Information:
- Motor: Specialized 1.2 SL Custom Rx, 50Nm torque
- Battery: Fully integrated 320Wh battery for extended range
- User Interface: MasterMind TCU, Bluetooth/ANT+, remote control on the handlebar
For riders who crave more trail time, the Turbo Levo SL Comp Alloy provides a balanced and natural-feeling pedal-assist, powered by the Specialized 1.2 SL motor. The FOX FLOAT suspension ensures a controlled, responsive feel over rocky and technical sections, while the SRAM GX Eagle drivetrain offers a wide gear range to suit every climb and descent. With durable alloy wheels and grippy Butcher and Eliminator tyres, it’s built to handle rough trails with ease.
The MasterMind TCU display lets you keep track of remaining power, adjust assist settings, and connect with Bluetooth or ANT+ devices. The Turbo Levo SL Comp Alloy is made to amplify your rides and help you reach new trails with confidence.
Occasionally, without notice, manufacturers change product design and/or specifications.
| Frame | Levo SL Alloy Frame, M5 alloy, 150mm travel, adjustable head angle, BB height, and compatible with 27.5 or 29" wheels |
| Fork | FOX FLOAT 36 Rhythm, GRIP damper, two position Sweep adjustment, 15x110mm QR axle, 44mm offset, S1:140mm of travel, S2-S6:150mm of travel |
| Rear Shock | FOX FLOAT Performance with Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-position lever w/ LSR adjustment, S1:210x52.5mm, S2-S6:210x55mm |
| Stem | Alloy Trail Stem, 35mm bar bore |
| Bars | Specialized, 6000 series alloy, 6-degree upsweep, 8-degree backsweep. S1-S2: 780 width, 20mm rise: S3-S4: 800 width, 30mm rise: S5-S6: 800 width, 40mm rise |
| Front Brake | SRAM Maven Bronze, 200mm Centerline rotor |
| Rear Brake | SRAM Maven Bronze, 200mm Centerline rotor |
| Brake Lever | SRAM Maven Bronze |
| Rear Mech | SRAM X01 Eagle, 12-speed |
| Shifters | SRAM GX Eagle, trigger, 12-speed, single click |
| Speed | 12 |
| Rims | Specialized 29, hookless alloy, 30mm inner width, tubeless ready |
| Front Hub | Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h |
| Rear Hub | Alloy, sealed cartridge bearings, 148mmx12mm thru-axle, 28h |
| Spokes | DT Swiss Industry |
| Front Tyre | Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3" |
| Rear Tyre | Eliminator, GRID GRAVITY casing, GRIPTON® T9/T7 compound, 27.5x2.3" |
| Seat Post | X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9, S1: 100mm, S2: 125mm, S3: 150mm, S4/S5: 170mm, S6: 190mm |
| Saddle | Bridge Comp, Hollow Cr-mo rails, 155/143mm |
| Chainset | SRAM S1000 Crankset, 32T ring, Integrated Guard, 55mm Chainline, 165mm |
| Chain | SRAM GX Eagle, 12-speed |
| Cassette | SRAM XG-1275, 12-speed, 10-52t |
| Pedals | Resin Platform |
| Battery Size (WH) | Specialized SL1-320, fully integrated, 320Wh |
| Motor | New Specialized 1.2 SL Custom Rx Trail Tuned Motor |
| User Interface | Specialized MasterMind TCU, percentage of remaining charge, 120 possible display configurations, MicroTune assist adjustment, ANT+/Bluetooth®, w/Handlebar remote |
Specialized Levo SL 2025 Size Chart
|
Size |
Height (Cm) |
Height (feet) |
|
S1 (XS) |
150 - 160 |
4’11” – 5’3” |
|
S2 (S) |
157 – 173 |
5’2” – 5’8” |
|
S3 (M) |
165 – 5’11 |
5’5” – 5’11” |
|
S4 (L) |
173 – 188 |
5’8” – 6’2” |
|
S5 (XL) |
178 – 193 |
5’10” – 6’4” |
|
S6 (XXL) |
188 - 203 |
6’2” – 6’8” |
Find your S Size
Determining your S-Size is easy. If you rode a Medium before, then S-3 will be your equivalent size. But if you want a more nimble ride, you should drop down to an S2. Want a bike that’s more stable at speed? Bump up to an S4. Following are examples of three riders, all 5’8” (1.73m), who chose three different sizes.
Specialized Turbo Levo SL 2025 Geometry Chart
| Frame Size | S1 | S2 | S3 | S4 | S5 | S6 |
|---|---|---|---|---|---|---|
| Stack | 609 | 617 | 626 | 635 | 645 | 654 |
| Reach | 405 | 425 | 445 | 470 | 495 | 525 |
| Head Tube Length | 95 | 100 | 110 | 120 | 130 | 140 |
| Head Tube Angle (°) | 64.5 | 64.5 | 64.5 | 64.5 | 64.5 | 64.5 |
| Bottom Bracket Height | 343 | 348 | 348 | 348 | 348 | 348 |
| Bottom Bracket Drop | -34 | -29 | -29 | -29 | -29 | -29 |
| Trail | 132 | 132 | 132 | 132 | 132 | 132 |
| Fork Length | 560 | 570 | 570 | 570 | 570 | 570 |
| Fork Rake/Offset | 44 | 44 | 44 | 44 | 44 | 44 |
| Front Centre | 726 | 752 | 776 | 806 | 835 | 869 |
| Chainstay Length | 433 | 432 | 432 | 432 | 432 | 432 |
| Wheelbase | 726 | 752 | 776 | 806 | 835 | 869 |
| Top Tube Length (horizontal) | 560 | 582 | 604 | 631 | 659 | 691 |
| Standover Height | 727 | 763 | 766 | 767 | 773 | 778 |
| Seat Tube Length | 385 | 385 | 405 | 425 | 445 | 465 |
| Seat Tube Angle (°) | 75.8 | 75.8 | 75.8 | 75.8 | 75.8 | 75.8 |
| Crank Length | 165 | 165 | 170 | 170 | 170 | 175 |
| Handlebar Width | 155 | 143 | 143 | 143 | 143 | 143 |
| Seatpost Max Insertion | 180 | 180 | 200 | 220 | 240 | 260 |
| Seatpost Min Insertion | 80 | 80 | 80 | 80 | 80 | 80 |
| Fork Travel | 144 | 150 | 150 | 150 | 150 | 150 |
All measurements are in mm unless otherwise stated.
The above table shows the standard geometry for the bicycle as shipped. Other geometry configurations may be available with certain bikes. Please contact us via Live Chat to find out more.
