Specialized Turbo Levo SL Pro Carbon 2025 - Electric Mountain Bike
With a carbon frame, efficient power delivery, and advanced suspension, the Turbo Levo SL Pro Carbon blends a lightweight feel with responsive handling. Ideal for riders who want to cover more ground on tough terrain without sacrificing control or agility.
Key Features:
- Fact 11m carbon frame, 150mm travel, adjustable head angle
- Fox 36 Factory fork with Grip X2 damper, Kashima coating, 150-160mm travel
- FOX FLOAT Performance Elite shock, 150mm, with GENIE air spring technology
- SRAM X0 Eagle 12-speed wireless transmission, smooth and precise
- SRAM Maven Silver brakes, HS2 200mm rotors, solid stopping power
- 29” Traverse HD wheels with Butcher and Eliminator tyres, 2.3" width
- Bike Yoke Revive Max dropper with smooth, responsive adjustment
- Available with 0% APR finance options
Drive Information:
- Motor: Specialized 1.2 SL Custom Rx motor, 50Nm torque
- Battery: Fully integrated 320Wh battery for extended range
- User Interface: MasterMind TCU, Bluetooth/ANT+ with handlebar remote
The Levo SL Pro Carbon is built for riders who dream of covering long, rugged trails with added power that feels natural. The lightweight carbon frame and Fox Factory suspension make it easy to control, even on technical descents, while the new Specialized 1.2 SL motor offers just the right torque for consistent support on the climbs. The SRAM X0 Eagle wireless drivetrain keeps shifts smooth and responsive, while the Bike Yoke dropper post ensures you’re always in control of your saddle height.
With the MasterMind TCU display, you can track your remaining charge, customise assist settings, and fine-tune every ride, making the Levo SL Pro Carbon your partner for a day filled with fun, challenging, and rewarding trail rides.
Occasionally, without notice, manufacturers change product design and/or specifications.
| Frame | Levo SL carbon Frame, Fact 11m carbon, alloy shock extension, 150mm travel, adjustable head angle, BB height, and compatible with 27.5 or 29" wheels. |
| Fork | Fox 36 Factory series, 29", Grip X2 damper, Kashima, S1: 150mm, S2-S6: 160mm |
| Rear Shock | FOX FLOAT Factory with Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-position lever w/3 setting Open mode tuning range, LSR adjustment, S1:210x52.5mm, S2-S6:210x55mm |
| Stem | Industry 9 A35 stem, 40mm length, 35mm clamp diameter |
| Bars | RaceFace Era Carbon, riser bar, 5-degree upsweep, 8-degree backsweep, S2:20mm Rise, S3-S6:40mm Rise, 800mm |
| Front Brake | SRAM Maven Silver w/Hs2 rotor, 200mm |
| Rear Brake | SRAM Maven Silver w/Hs2 rotor, 200mm |
| Brake Lever | SRAM Maven Silver |
| Rear Mech | SRAM X0 Eagle Transmission Derailleur |
| Shifters | SRAM AXS POD Controller |
| Speed | 12 |
| Rims | Traverse HD 350 |
| Front Hub | Traverse HD 350, 29" |
| Rear Hub | Traverse HD 350, 27.5", XD freehub body |
| Front Tyre | Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3" |
| Rear Tyre | Eliminator, GRID GRAVITY casing, GRIPTON® T9/T7 compound, 27.5x2.3" |
| Seat Post | Bike Yoke, Revive Max, 34.9, S1: 125mm, S2: 160mm, S3-S4: 185mm, S5-S6: 213mm |
| Saddle | Industry 9 A35 stem, 40mm length, 35mm clamp diameter |
| Chainset | SRAM Eagle Crankset, 32T ring, Integrated Guard, 55mm Chainline, 165mm |
| Chain | SRAM X0 Eagle Transmission Flattop Chain |
| Cassette | SRAM X0 Eagle Transmission Cassette, 12spd, 10-52t |
| Pedals | Resin Platform |
| Weight | 18.15 kg |
| Battery Size (WH) | Specialized SL1-320, fully integrated, 320Wh |
| Motor | New Specialized 1.2 SL Custom Rx Trail Tuned Motor |
| User Interface | Specialized MasterMind TCU, percentage of remaining charge, 120 possible display configurations, MicroTune assist adjustment, ANT+/Bluetooth®, w/Handlebar remote |
Specialized Levo SL 2025 Size Chart
|
Size |
Height (Cm) |
Height (feet) |
|
S1 (XS) |
150 - 160 |
4’11” – 5’3” |
|
S2 (S) |
157 – 173 |
5’2” – 5’8” |
|
S3 (M) |
165 – 5’11 |
5’5” – 5’11” |
|
S4 (L) |
173 – 188 |
5’8” – 6’2” |
|
S5 (XL) |
178 – 193 |
5’10” – 6’4” |
|
S6 (XXL) |
188 - 203 |
6’2” – 6’8” |
Find your S Size
Determining your S-Size is easy. If you rode a Medium before, then S-3 will be your equivalent size. But if you want a more nimble ride, you should drop down to an S2. Want a bike that’s more stable at speed? Bump up to an S4. Following are examples of three riders, all 5’8” (1.73m), who chose three different sizes.
Specialized Turbo Levo SL 2025 Geometry Chart
| Frame Size | S1 | S2 | S3 | S4 | S5 | S6 |
|---|---|---|---|---|---|---|
| Stack | 609 | 617 | 626 | 635 | 645 | 654 |
| Reach | 405 | 425 | 445 | 470 | 495 | 525 |
| Head Tube Length | 95 | 100 | 110 | 120 | 130 | 140 |
| Head Tube Angle (°) | 64.5 | 64.5 | 64.5 | 64.5 | 64.5 | 64.5 |
| Bottom Bracket Height | 343 | 348 | 348 | 348 | 348 | 348 |
| Bottom Bracket Drop | -34 | -29 | -29 | -29 | -29 | -29 |
| Trail | 132 | 132 | 132 | 132 | 132 | 132 |
| Fork Length | 560 | 570 | 570 | 570 | 570 | 570 |
| Fork Rake/Offset | 44 | 44 | 44 | 44 | 44 | 44 |
| Front Centre | 726 | 752 | 776 | 806 | 835 | 869 |
| Chainstay Length | 433 | 432 | 432 | 432 | 432 | 432 |
| Wheelbase | 726 | 752 | 776 | 806 | 835 | 869 |
| Top Tube Length (horizontal) | 560 | 582 | 604 | 631 | 659 | 691 |
| Standover Height | 727 | 763 | 766 | 767 | 773 | 778 |
| Seat Tube Length | 385 | 385 | 405 | 425 | 445 | 465 |
| Seat Tube Angle (°) | 75.8 | 75.8 | 75.8 | 75.8 | 75.8 | 75.8 |
| Crank Length | 165 | 165 | 170 | 170 | 170 | 175 |
| Handlebar Width | 155 | 143 | 143 | 143 | 143 | 143 |
| Seatpost Max Insertion | 180 | 180 | 200 | 220 | 240 | 260 |
| Seatpost Min Insertion | 80 | 80 | 80 | 80 | 80 | 80 |
| Fork Travel | 144 | 150 | 150 | 150 | 150 | 150 |
All measurements are in mm unless otherwise stated.
The above table shows the standard geometry for the bicycle as shipped. Other geometry configurations may be available with certain bikes. Please contact us via Live Chat to find out more.
