Trek Domane AL 5 Gen 4 2027 - Road Bike







The Trek Domane AL 5 Gen 4 is an endurance road bike built to go further in comfort. A lightweight aluminium frame, full carbon fork and Shimano 105 drivetrain make it ideal for long rides, commuting and weekend training.
Key Features:
- 100 Series Alpha Aluminium frame with endurance geometry and internal routing
- Domane AL full carbon fork with tapered steerer and internal brake routing
- Shimano 105 R7100 2x12-speed drivetrain with wide-range gearing
- Shimano 105 hydraulic disc brakes
- Bontrager alloy wheels with Kwaremont Comp 700x32c tyres
- Rack, mudguard and top tube bag mounts for added versatility
- Available with 0% APR finance
The Trek Domane AL 5 Gen 4 is built for riders who want the speed of a road bike with the comfort to tackle longer distances. Whether you're training for sportives, joining weekend club rides or commuting during the week, it combines dependable performance with everyday practicality in a well-rounded package.
The frame is constructed from Trek's lightweight 100 Series Alpha Aluminium and features an endurance-focused geometry that places you in a comfortable, efficient riding position for long hours in the saddle. Internal cable routing gives the bike a clean, premium appearance, while a tapered head tube improves front-end stiffness and steering precision. Trek has also transitioned this frame to lower-emission aluminium produced using renewable energy, helping reduce the environmental impact of manufacture.
A full carbon Domane AL fork keeps weight down while helping absorb vibration from rough roads, improving comfort without sacrificing responsive handling. Internal brake routing maintains the bike's clean lines, while integrated mudguard mounts add practicality for year-round riding.
The Shimano 105 R7100 2x12-speed drivetrain delivers the crisp, dependable shifting that has made 105 a favourite among performance-focused riders. Borrowing technology from Shimano's Ultegra and Dura-Ace groupsets, it combines a compact 50/34T chainset with an 11-34T cassette to provide a broad range of gears for steep climbs, fast descents and everything in between.
Shimano 105 hydraulic disc brakes offer powerful, predictable braking in all weather conditions. Excellent modulation and consistent stopping performance inspire confidence whether you're descending quickly or riding through wet winter roads.
Bontrager alloy wheels are paired with Bontrager Kwaremont Comp 700x32mm tyres featuring Hard-Case Lite puncture protection. The wider tyres improve grip and comfort on imperfect road surfaces, while generous tyre clearance also allows larger tyres to be fitted for light gravel riding and mixed-surface adventures.
Practical mounting points for mudguards, a rear rack, top tube bag and multiple bottle cages make it easy to tailor the Domane AL 5 for commuting, touring or long-distance riding. The Universal Derailleur Hanger (UDH) also simplifies sourcing replacement hangers should the need arise.
The updated Bontrager handlebar features a subtle flare between the hoods and drops for greater comfort and control, while the Blendr-compatible stem makes it easy to mount compatible lights and cycling computers neatly.
Built on Trek's racing heritage but designed with versatility in mind, the Domane AL 5 Gen 4 is a road bike that rewards riders as their ambitions grow. Its blend of comfort, reliable Shimano 105 performance and everyday practicality makes it an excellent choice for riders looking to cover more miles with confidence.
Occasionally, without notice, manufacturers change product design and/or specifications.
| Frame | 100 Series Alpha Aluminium, tapered head tube, internal routing, mudguard mounts, flat-mount disc, UDH, 142x12 mm thru axle |
| Fork | Domane AL carbon, tapered carbon steerer, internal brake routing, mudguard mounts, flat-mount disc, 12x100 mm thru axle |
| Stem | Bontrager Elite, 31.8 mm, Blendr-compatible |
| Bars | Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop |
| Front Mech | Shimano 105 R7100, 31.8 mm clamp, down swing |
| Rear Mech | Shimano 105 R7100, 36T max cog |
| Speed | 11 |
| Front Hub | Bontrager alloy, sealed bearing, CentreLock disc, 100x12 mm thru axle |
| Rear Hub | Bontrager alloy, sealed bearing, CentreLock disc, Shimano 11-speed freehub, 142x12 mm thru axle |
| Front Tyre | Bontrager Kwaremont Comp, Hard-Case Lite, wire bead, 60 tpi, 700x32 mm |
| Rear Tyre | Bontrager Kwaremont Comp, Hard-Case Lite, wire bead, 60 tpi, 700x32 mm |
| Seat Post | Bontrager Comp, 6061 alloy, 27.2 mm |
| Saddle | Verse Short Comp, steel rails, 145 mm width |
| Chainset | Shimano 105 R7100, 50/34 |
| Bottom Bracket | Shimano RS501 BSA |
| Chain | Shimano SLX M7100, 12-speed |
| Cassette | Shimano 105 7101, 11-34, 12-speed |
Trek Domane AL Gen 4 Sizing Guide
| Size | Height cm | Height Feet / Inches | Inseam cm | Inseam Inches |
|---|---|---|---|---|
| 44 | 150 - 153 cm | 4'11" - 5'0" | 71 - 73cm | 28" - 29" |
| 49 | 158 - 163 cm | 5'1" - 5'4" | 74 - 77 cm | 29" - 30" |
| 52 | 163 - 168 cm | 5'4" - 5'6" | 76 - 79 cm | 30" - 31" |
| 54 | 168 - 174 cm | 5'6" - 5'9" | 78 - 82 cm | 31" - 32" |
| 56 | 174 - 180 cm | 5'9" - 5'11" | 81 - 85 cm | 32" - 33" |
| 58 | 180 - 185 cm | 5'11" - 6'1" | 84 - 87 cm | 33" - 34" |
| 60 | 185 - 190 cm | 6'1" - 6'3" | 86 - 90 cm | 34" - 35" |
What size frame do I need if I am between sizes? - read here
Trek Domane AL Gen 4 Geometry Chart
| Size | 44cm | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|---|
| Stack | 510 | 540 | 561 | 575 | 591 | 611 | 646 |
| Reach | 360 | 368 | 371 | 374 | 377 | 380 | 385 |
| Head Tube Length | 95 | 123 | 145 | 160 | 175 | 195 | 235 |
| Head Tube Angle | 70.3° | 70.8° | 71.3° | 71.3° | 71.9° | 72.0° | 72.1° |
| Bottom Bracket Drop | 80 | 80 | 80 | 80 | 78 | 78 | 75 |
| Trail | 66 | 66 | 59 | 59 | 61 | 60 | 63 |
| Fork Rake/Offset | 53 | 53 | 53 | 53 | 48 | 48 | 48 |
| Chainstay Length | 420 | 425 | 420 | 420 | 420 | 425 | 425 |
| Wheelbase | 983 | 1001 | 100.3 | 101.0 | 101.8 | 102.2 | 103.8 |
| Top Tube Length (horizontal) | 505 | 516 | 530 | 542 | 554 | 567 | 586 |
| Standover Height | 657 | 717 | 735 | 754 | 776 | 796 | 842 |
| Seat Tube Length | 390 | 440 | 475 | 500 | 525 | 548 | 576 |
| Seat Tube Angle | 74.6° | 74.6° | 74.2° | 73.7° | 73.3° | 73.0° | 72.7° |
All measurements are in mm unless otherwise stated.
The above table shows the standard geometry for the bicycle as shipped, other geometry configurations may be available with certain bikes. Please contact us via Live Chat to find out more.
